| Waste management is the prevention, monitoring, handling and the residual disposition of MSW (Mixed Solid Waste). | ||
|
|
|
| Waste management is the prevention, monitoring, handling and the residual disposition of MSW (Mixed Solid Waste). | ||
SWATCH PLASMA: PLASMA CORE MACHINE EB500A 1200 Kg capacity Super Waste Decomposition Machine Waste destruction System with double layered Venturi water pump wet scrubber with purging system and 6Mtr. height MS Constructed Chimney
DIMENSIONS Net Weight – 1.5 Ton Machine Footprint – W-4 . 5′ x L -10 . 5′ x H-8 . 5′ Shed Area Required – W-5mtr x L-10mtr x H-6mtr Land Area Required – 100 Sq. Meters
SWATCH PLASMA: PLASMA CORE MACHINE EB1000A 2400 Kg capacity Super Waste Decomposition Machine Waste destruction System with double layered Venturi water pump wet scrubber with purging system and 6Mtr. height MS Constructed Chimney
DIMENSIONS Net Weight – 3 Tonnes Machine Footprint – W – 5′ x L – 11′ x H – 9′ Shed Area Required – W – 5 m tr x L – 10m t r x H – 6m tr Land Area Required – 120 Sq. Meters
SWATCH PLASMA: PLASMA CORE MACHINE EB1500A 3600Kg capacity Super Waste Decomposition Machine Waste destruction System with double layered Venturi water pump wet scrubber with purging system and 6Mtr. height MS Constructed Chimney
DIMENSIONS Net Weight – 7 .Tonnes Machine Footprint – W – 6′ x L – 12′ x H – 10′ Shed Area Required – W- 5mtr x L- 10mtr x H- 6mtr Land Area Required – 150 Sq. Meters
SWATCH PLASMA: PLASMA CORE MACHINE EB2000A 4800 Kg capacity Super Waste Decomposition Machine Waste destruction System with double layered Venturi water pump wet scrubber with purging system and 6Mtr. height MS Constructed Chimney
DIMENSIONS Net Weight – 10 Tonnes Machine Footprint – W – 9′ x L – 15′ x H – 13′ Shed Area Required – W – 5 mt r x L – 10 mt r x H – 6 m tr Land Area Required – 220 Sq. Meters
SWATCH PLASMA: PLASMA CORE MACHINE EB1000A 2400 Kg capacity Super Waste Decomposition Machine Waste destruction System with double layered Venturi water pump wet scrubber with purging system and 6Mtr. height MS Constructed Chimney.
DIMENSIONS Net Weight – 3 Tonnes Machine Footprint – W – 5′ x L – 11′ x H – 9′ Shed Area Required – W – 5 m tr x L – 10m t r x H – 6m tr Land Area Required – 120 Sq. Meters
|
||
Technical Specifications |
||
ECO BEAN |
Model |
EB 5000 A |
Material of Construction |
M.S. Construction |
|
Type Of System |
Magnetic Thermal Waste Destruction System |
|
Operating Temperature |
350 -800 Degree Celsius |
|
Insulation |
Rock Wool Heat proof Insulation |
|
Safety Features |
Pressure release valve, Temperature Monitoring Sensor |
|
Scrubber Details |
Multi Stage Scrubber and second heater in flue gas pipe to treat the flue gases emitted from stack |
|
Exhaust Chimney |
10mtrs (30 Feet) height MS chimney |
|
Sludge collection |
Water tank with sludge Ejector system |
|
Ash collection |
As chamber fixed with damper technology |
|
Waste Destruction |
Waste Destruction Capacity per 24 Hr Volumetrically |
30 Cubic M |
Waste Destruction Capacity per 24 Hr Approx. Weight |
12000 Kg |
|
Type of Material |
Material For Destruction |
Mixed Solid Waste (wet and dry),paper waste , carton ,Plastic , Polyethylene bags ,Organic waste ,Plastic sheet and plastic scraps |
Material Characteristics |
Solid Waste with less moisture (50%). Avoid Water / Liquid MSW Waste |
|
Material exempted |
Stones, Metals, Glass, Ceramic |
|
Feeding Process |
AUTO (Shredder with screw conveyor) |
|
Electrical Consumption per 8Hr |
For initial ignition |
1 -20Units |
For Destruction |
0 |
|
For Scrubbing & Feeding |
50-60Units |
|
Power Source |
AC 420 V Three Phase |
|
Utilities |
Shed Size (LXWXH) |
50 M X 10M X 6 M |
Water Req. |
500 Ltr. |
|
Man power Req. |
Two Persons per shift to operate the machine |
|
